SCH1025D-K1
2013-05-16





Product category: Bus/truck > SCH1025D-K1
Product name: SCH1025D-K1
Product Number: YCV1
Product Description:
Item SCH1025D-K1 SCH1025S
NO A/C A/C NO A/C A/C
Dimension parameters
Item SCH1025D-K1 SCH1025S
Vehicle dimension(L*W*H) mm      4780*1636*1850 4680*1636*1850
Cargo Box Dimension(L*W*H) mm     2900*1540*350 2000*1540*350
Wheelbase mm 2850 2850
Track(front/rear) mm 1386/1408 1380/1408
Front overhang mm 580 580
Rear overhang mm 1350 1250
Engine
Model HH465QE6/HH412Q/P HH465QE6/HH412Q/P
Displacement ml 997/1206 997/1206
Compression Ratio 10:01/9.8:1 10:01/9.8:1
Power Kw/rpm 45/63 45/63
Max. Torque N.M/rpm 86/108 86/108
Mass Parameter
Total Mass Kg 2120 2120
Curb Mass Kg 1000 1100
Rated Payload Kg 990 695
Seat Person 2 5
